Long Shadow Filter Component

Overview

This component adds a visual shadow effect to the UI object it is applied to.

WebGL Demo

Properties

Property	Type	Details
Distance
Method	Enum	Which rendering method to use. Options are: • Normal - This is best for shorter shadows, it's high quality but can become very slow for shadows with a high Distance value. (DEFAULT) • DistanceMap - This is very fast for shadows with a high Distance value, but the quality of the edge is not as high as the Normal method.
Long Shadow
Angle	Float	The angle that shadow is cast in degrees. Default value is 135, range is [0..360].
Distance	Float	The distance in pixels that the shadow is cast. Default value is 32, range is [-1024..1024].
Step Size	Float	The number of pixels to step over, it can be used to create a more pixel-art style. Default is 1.0, range is [0..64].
Color Front	Color	The front color of the shadow.
Use Back Color	Bool	Whether to use the back color. If disabled the shadow will just be a single color. If enabled the shadow will have a front and back color with the gradient between the two.
Color Back	Color	The back color of the shadow.
Pivot	Float	The pivot can be used for animating the shadow. A value of -1 means the front is located at the position of the back. A value of 0.0 means the front and back are at their furthest distance apart. A value of 1.0 means the back is located at the position of the front. Range is [-1..1]. Default is 0.0
Apply
Source Alpha	Float	Fades the source Graphic. Default value is 1.0, range is [0..1]
Mode	Enum	Which mode to use when compositing the shadow. Options are: • Normal - Long shadow is composited behind the source graphic. (DEFAULT) • Cutout - Shadow is rendered with the source graphic cut out from it. • Shadow - Only the shadow is rendered.
Strength	Float	Strength of the effect. Default value is 1.0, range is [0..1]
Render Space	Enum	Which coordinate system use when rendering this filter. Options are: • Canvas: Render the filter before any transforms (scale/rotation/translation etc) are applied. • Screen: Render the filter after transforms have been applied. Read more about this property here.
Expand	Enum

Usage

Add this component to any GameObject that contains a UI Graphic component (eg Text, Image, RawImage, etc). The object will now render with a long shadow.

Usage with TextMeshPro

To use this filter effect with TextMeshPro - Text (UI) use the Filter Stack (TextMeshPro) component.

Examples

Angle

Dual Color

Pivot

Scripting

Namespace

The namespace

using ChocDino.UIFX;

Adding the LongShadowFilter Component

Add the LongShadowFilter component to your GameObject

// Add the component to your GameObject and set default properties
var shadow = AddComponent<LongShadowFilter>();

shadow.BeginPropertyChange();
shadow.Method = LongShadowMethod.Normal;
shadow.Angle = 135f;
shadow.Distance = 8f;
shadow.StepSize = 1f;
shadow.FrontColor = Color.black;
shadow.UseBackColor = false;
shadow.BackColor = Color.clear;
shadow.Pivot = 0f;
shadow.SourceAlpha = 1f;
shadow.CompositeMode = LongShadowCompositeMode.Normal;
shadow.Strength = 1f;
shadow.EndPropertyChange();
